ID produit (Product ID):
THZ611
Marque (Brand):
Dwyer
Catégorie (Category):
Plumbing Equipment & Supplies
Sous-catégorie (Sub-category):
Ball Valve
Spécifications supplémentaires (Additional Specs):
Cv 7.5
Attributs (Attributes):
Material Brass Mechanism Type Manual Pipe/Hose Diameter 3/8" Connection Type FNPT x FNPT
Fonctionnalités (Features):
; Body: Two-Piece ; End Connections: 1/4" to 3" female NPT ; Pressure Limits: 1/4" to 1": 600 PSI (41.4 bar), 1 1/4" to 2": 400 PSI (27.6 bar), 2 1/2 to 3": 200 PSI (13.8 bar) WOG ; Wetted Materials: Body and body cap: forged brass (ASTM B283-C37700); ball and stem: brass; seat and packing Teflon® Temperature Limits: 10 to 200 °F (-12 to 93 °C) ; Other Materials: Body seal: rubber; handle: plated steel; nut and gasket: brass
Description de l’unité (Unit Description):
Each
