ID535 (ID535)

ID produit (Product ID): ID535
Marque (Brand): Fluke
Catégorie (Category): Tools
Sous-catégorie (Sub-category): Power Quality Analyzer
Spécifications supplémentaires (Additional Specs): Includes Power Analyzer; Test Leads - (4) Red, (4) Black, (8) Blue; Alligator Clips (4) Red, (4) Black, (8) Blue; USB (Mini B) Cable; RS-485/Synchrony Adapter; Soft Carrying Case; Power Supply Adapter; Power Cord; USB Flash Drive for PC SW and User Manual Inputs 4 Voltage + 4 Current Sample Rate 200 ks/s Measurement Update Rate 100 ms, 200 ms, 500 ms, 1s Data Trend Storage Rate As Per Display Rate Main Function Meter, Scope, Harmonic, Phasor, Trend Measuring Parameters RMS, DC Component, AC Component, Rectified Mean, Peak Value, Peak-Peak, Crest Factor, Form Factor, Fundamental Component, Fundamental Content, Harmonic Distortion, Harmonic Content, Harmonic Factor for voltages and currents, Active Power, Reactive Power, Apparent Power, Power Factor, Phase Shift, Efficiency, Impedance, Electric Energy, Charge/Discharge capacity (Ah), Frequency Electrical Range 10, 100, 1000 V Crest Factor CF ≤2
Attributs (Attributes): Display Digital No. of Phases 3
Fonctionnalités (Features): Designed for portability, the lightweight, battery-powered analyzer eliminates the need to carry large, fragile, expensive analyzers into the field By measuring directly at the load, you can discover how the equipment operates under real-world conditions, with real-world variables Includes four measurement channels, giving it the capability to measure three-phase power and DC power simultaneously Key measurements: Voltage, current, active power, reactive power, apparent power, power factor, and harmonics with associated values High accuracy and wide bandwidth - 0.1% measurement accuracy and 500 kHz bandwidth Highly portable and easily installed in tight spaces - only 3.78" (9.6 cm) thick Operate continuously for up to 10 hours without an external power supply using the 5000 mAh Li-ion internal battery Measure safely - safety rated for CAT III 1000V, CAT IV 600 V environments Measure three phase power and DC output power at the same time with four channels, with voltage and current inputs on each channel 0.1% accuracy, 500 kHz bandwidth, 200 ks/s sample rate so you can rely on the power conversion system measurements you take no matter what distortion may be present USB and RS485 interface and open communication protocol for easy system integration and software platform flexibility Combine two analyzers to enable simultaneous measurement of multiple circuits for even more troubleshooting capability - configurable to 6 or 8 channels using dual analyzer synchronization View critical data in the field on the main display - Meter, Waveform, Harmonics up to the 100th, Vector and Trend Ensure high common-mode rejection and allow flexible configurations according to measurement requirements using the electrically isolated channels User adjustable measurement rate from 100 ms to 1 s with continuous logging via 32GB of onboard storage Easy in-field set up using the integrated front panel or a remote PC connection (USB or RS485) Online measuring, data download and analysis with included PC software (Fluke Power Analyzer Software) Full remote control of the connected instrument using Fluke Power Analyzer Software and a local USB or long-distance RS485 connection
Description de l’unité (Unit Description): Each
